General Description
AT1688Z is a highly integrated quasi-resonant (QR) mode PWM control for flyback converter, optimized for high
performance, low standby power consumption and cost effective offline flyback converter applications.
The AT1688Z internal valley detector ensures minimum drain voltage switching at QR operation. At low line and
heavy loading, it operates in continuous conduction mode(CCM) via an external resistor sets minimum fixed frequency.
At high line and normal loading, it operates in QR mode. When light load, it operates in pulse frequency
modulation (PFM) mode. When the output power falls below a given level, it enters the burst mode.
The AT1688Z built-in multiple protection with VCC under voltage lockout (UVLO), VCC over voltage protection
(OVP), VCC clamp, GATE clamp, internal over temperature protection (OTP), Output over voltage protection, DEM
high level protection, cycle-by-cycle current limiting (OCP), over load protection (OLP), X-cap discharge, brown in/out
protection, and leading-edge blanking (LEB) of the current sensing to prevent circuit damage occurred under abnormal
conditions.
The AT1688Z is available in an SOP-10L package and require very few external devices for operation.

650W Pick~810W AT6103+AT1688+AT6902 54V 12A 音響

Low Cost

General Description
AT1687Z is a highly integrated quasi-resonant (QR) mode PWM control for flyback converter, optimized for high
performance, low standby power consumption and cost effective offline flyback converter applications.
The AT1687Z internal valley detector ensures minimum drain voltage switching at QR operation. At low line and
heavy loading, it operates in continuous conduction mode(CCM) via an external resistor sets minimum fixed frequency.
At high line and normal loading, it operates in QR mode. When light load, it operates in pulse frequency
modulation (PFM) mode. When the output power falls below a given level, it enters the burst mode.
The AT1687Z built-in multiple protection with VCC under voltage lockout (UVLO), VCC over voltage protection
(OVP), VCC clamp, GATE clamp, internal over temperature protection (OTP), Output over voltage protection, DEM
high level protection, cycle-by-cycle current limiting (OCP), over load protection (OLP), and leading-edge blanking
(LEB) of the current sensing to prevent circuit damage occurred under abnormal conditions.
The AT1687Z is available in an SOP-10L package and require very few external devices for operation.

General Description
AT6002H is a highly integrated current mode PWM control for flyback converter, optimized for high performance,
low standby power consumption and cost effective offline flyback converter applications.
The AT6002H built-in multiple protection with VCC under voltage lockout (UVLO), VCC over voltage protection
(OVP), VCC clamp, GATE clamp, cycle-by-cycle current limiting (OCP), over load protection (OLP), RT Low Level
Protection(RTLP), RT High Level Protection(RTHP), and leading-edge blanking (LEB) of the current sensing to
prevent circuit damage occurred under abnormal conditions.
The AT6002H also has an X-cap discharge function to discharge the X-cap when the input is unplugged and Brownout
protection function.
The AT6002H is available in an SOP-8L package and require very few external devices for operation.
